Section 9
ILLUSTRATIONS AND PARTS LIST
59
9.9 FLUID PIPING SYSTEM- AIR-COOLED
key part
number description number quantity
1 mounting, bracket oil filter 20/12 02250061-327 1
2 tube, oil stop valve adapter 02250075-105 1
3 mt, filter 80cn full flow 02250075-158 1
4 flange, kit sae splt 2” - viton 02250099-415 2
5 seal, u-cup therm vlv 02250101-372 1
6 filter, oil assy parker (I) 02250111-592 1
7 flange, adapter 2”split flg/1-7/8”st 02250120-980 1
8 tube, therm vlv/oil filt ls20t wc 02250135-510 1
9 tube, thrmvlv/clr 1-1/2” ls20t 02250137-683 1
10 tube, clr/thrmvlv 1-1/2” ls20t 02250148-214 1
11 housing, therm valve (II) 221947 1
12 element, thermal vlv 220deg f 250001-349 1
13 flange, thermal valve 1 1/2” 250001-458 1
14 valve, oil stop 2” sae code 61 (III) 250041-069 1
15 connector, tube-m 1 1/2 x 1 1/2 810224-150 2
16 elbow, tube 90 deg m 1 1/2 x 1 1/2 810524-150 1
17 elbow, tube str thrd 1 1/2 x 1 7/8 811624-188 2
18 connector, tube str thd 1 1/2 x 1 7/8 811824-188 1
19 nut, hex f pltd 3/8-16 825306-347 2
20 o-ring, viton 2 1/4 x 1/8” 826502-228 1
21 o-ring, viton 2 3/4 x 1/8” 826502-232 1
22 capscrew, hex gr5 3/8-16 x 1 1/4 829106-125 4
23 capscrew, hex gr5 5/8-11 x 1 1/4 829110-125 2
24 screw, hex ser washer 5/16-18 x 3/4 829705-075 4
25 screw, hex ser washer 3/8-16 x 1 829706-100 2
26 washer, spr lock reg pltd 3/8 837806-094 4
27 washer, spr lock reg pltd 5/8 837810-156 2
28 washer, pl-b reg pltd 5/8 838210-112 2
(I) For maintenance on fluid filter assembly no. 02250111-592, order replacement element no. 250031-
850.
(II) For maintenance on thermal valve assembly, order repair kit no. 250016-929.
(III) For maintenance on fluid stop valve no. 250041-069, order repair kit no. 02250051-747.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
Continued on page 61
