Sumitomo Beier Variator Series - Beier Cyclo Variator Specifics; Rating Plate Identification; Lubrication Method; Confirming Lubrication Method

4
MODEL
RATIO
INPUT
OUTPUT TORQUE
SERIAL NO.
BEIER SPEED RANGE
R
AN9077G
JAPAN
kW r/min
N-m AT MAX. SPEED
N-m AT MIN . SPEED
1Model name
(Refer to page 5)
3Speed Rang
· Motor capacity speed
· Allowable output
torque
4Serial No.
Fig.3 Rating Plates of Beier-Cyclo Variator
2Cyclo Reducer Ratio
Same as page 3.
Beier Cyclo Variator
(1) Beier Cyclo
(2) Motor
COMMON
1-2) Lubrication Method
Refer to "8-2. Confirmation of Lubrication Method" on page 17 to confirm the lubrication method.
• Oil-lubricated models are shipped without oil. Units must be filled with the proper amount of recommended oil prior
to start-up.
