FINE CYCLO Operating Manual
FC_GB_01_05 NO.991051 Issue: 01/05 page 2
Dangerous situation
Risk of physical injury
1. General information
Please observe the following warnings
Helpful information
Disposal
Please observe legal /environmental regulations.
Do not attempt to install or operate the FINE CYCLO reduction assembly until all of these instructions
on assembly, operation, maintenance and inspection and hazards are read and thoroughly under-
stood. Please keep these instructions next to the unit in operation to check at any time when neces-
Transportation, assembly, lubrication, operation, maintenance and inspection should only be done by
qualified personnel, so as to avoid personal injury or damage to property.
Do not touch moving mechanical components and make sure these parts are clear of obstructions.
Failure to follow these instructions may result in personal injury, unit failure or damage to property.
Only operate the unit in the application it was intended. Misapplication may result in physical injury or
damage to machinery.
2. Safety advice
The units must be checked for any transportation damage immediately upon receipt. Any damages
should be reported to the carrier without delay. If there is any evidence of damage which may put at
risk the function of the FINE CYCLO reduction assembly, do not install the unit.
3. Transportation recommendations
In the case of speed reducers with hollow high speed shafts, MoS
2
paste or spray (e.g. Molykote) is
to be applied to the motor shaft before it is connected.
4. Connection of other transmission components
Imminent danger
Misapplication of the machine may be dangerous and lead to severe injuries
Important remarks for explosion protection
Clutches, discs, gear wheels, chains, etc. should be mounted on the reducer shafts carefully.
Do not force them onto the shafts as this could damage the gearbox bearings.
Damaging situation
Risk of machine damage.
