60
BASE INSTALLATION WITH VEHICLE LAP/SHOULDER BELT
Grab the base at the belt guides and pull
from side to side and front to back to make
sure it is installed correctly. The base should
not move more than 1 inch (2.5 cm) in any
direction.
If the base moves too much, open the belt
tensioning arm and remove a little more
slack from the vehicle belt, close arm and
re-check. After this, if the base still moves
too much, you may need to try a different
vehicle seat location or installation method,
or both.
You can switch the shoulder belt retractor
into locking mode by pulling out shoulder
belt all the way and then letting it rewind into
the retractor. Pull on the belt to make sure it
is locking.
6
