Sun Microsystems GDM-5010PT User Manual

GDM-5010PT
2-7. SERVICE POSITION
2-4
2-8. H1, H2 AND J BOARDS REMOVAL
D board (Refer to 2-2.)
Rear shield
D,G boards
A board (Refer to 2-4.)
G board
(Refer to 2-3.)
CAUTION : SHORT
If the claw is hooked,
opening and closing
the board is impossible.
Do not try to do it by force.
If the claw is hooked,
opening and closing
the board is impossible.
Do not try to do it by force.
Four screws
(Tapping screw 5)
CN801
H1 board
Bezel
5
6
8
Two screws
(+ BVTP 3 x 10)
7
Screw
(+ BVTP 3 x 10)
9
Claw
J board
CN891
Claw
Two claws
12
11
H2 board
10
Hook (20)
4
Screw
(+ BVTP 4 x 16)
3
Hook (20)
2
Screw
(+ BVTP 4 x 16)
1
