Sun Microsystems GDM-5010PT - Timing Specification

GDM-5010PT
– 4 –
TIMING SPECIFICATION
MODE AT PRODUCTION MODE 1 MODE 2
RESOLUTION 1280 X 1024 1152 X 900
CLOCK 135.000 MHZ 108.000 MHZ
-- HORIZONTAL --
H-FREQ 81.130 kHz 71.809 kHz
usec usec
H. TOTAL 12.326 13.926
H. BLK 2.844 3.259
H. FP 0.237 0.296
H. SYNC 0.474 1.185
H. BP 2.133 1.778
H. ACTIV 9.481 10.667
-- VERTICAL --
V. FREQ(HZ) 76.107 Hz 76.149 Hz
lines lines
V. TOTAL 1066 943
V. BLK 42 43
V. FP 2 2
V. SYNC 8 8
V. BP 32 33
V. ACTIV 1024 900
-- SYNC --
INT(G) NO NO
EXT(H/V)/POLARITY NO NO
EXT(CS)/POLARITY YES N YES N
INT/NON INT NON INT NON INT
97.12.10 Ver.
