REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5010PT
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
R618 1-215-477-00 METAL 220K 1% 1/4W
R619 1-215-485-00 METAL 470K 1% 1/4W
R620 1-215-485-00 METAL 470K 1% 1/4W
R621 1-215-481-00 METAL 330K 1% 1/4W
R622 1-216-049-91 RES,CHIP 1K 5% 1/10W
R623 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R624 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R625 1-249-389-11 CARBON 4.7 5% 1/4W
R626 1-249-429-11 CARBON 10K 5% 1/4W
R627 1-215-479-00 METAL 270K 1% 1/4W
R628 1-215-481-00 METAL 330K 1% 1/4W
R629 1-215-461-00 METAL 47K 1% 1/4W
R631 1-247-807-31 CARBON 100 5% 1/4W
R632 1-216-073-00 RES,CHIP 10K 5% 1/10W
R633 1-215-481-00 METAL 330K 1% 1/4W
R635 1-216-073-00 RES,CHIP 10K 5% 1/10W
R640 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R641 1-218-642-11 METAL OXIDE 100K 5% 1W F
R642 1-218-642-11 METAL OXIDE 100K 5% 1W F
R643 1-247-863-91 CARBON 22K 5% 1/4W
R644 1-216-105-91 RES,CHIP 220K 5% 1/10W
R645 1-216-081-00 RES,CHIP 22K 5% 1/10W
R646 1-216-073-00 RES,CHIP 10K 5% 1/10W
R647 1-249-441-11 CARBON 100K 5% 1/4W
R648 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R649 1-218-642-11 METAL OXIDE 100K 5% 1W F
R650 1-218-642-11 METAL OXIDE 100K 5% 1W F
R651 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R652 1-212-942-00 FUSIBLE 2.2 5% 1/2W F
R655 1-216-073-00 RES,CHIP 10K 5% 1/10W
R661 1-249-387-11 CARBON 3.3 5% 1/4W F
R662 1-216-073-00 RES,CHIP 10K 5% 1/10W
R663 1-216-073-00 RES,CHIP 10K 5% 1/10W
R664 1-247-791-91 CARBON 22 5% 1/4W
R665 1-216-033-00 RES,CHIP 220 5% 1/10W
R666 1-215-441-00 METAL 6.8K 1% 1/4W
R667 1-215-433-00 METAL 3.3K 1% 1/4W
R668 1-249-401-11 CARBON 47 5% 1/4W
R669 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R671 1-216-113-00 RES,CHIP 470K 5% 1/10W
R672 1-216-049-91 RES,CHIP 1K 5% 1/10W
R673 1-249-413-11 CARBON 470 5% 1/4W F
R674 1-249-377-11 CARBON 0.47 5% 1/4W F
R675 1-260-292-11 CARBON 1 5% 1/2W
R676 1-249-413-11 CARBON 470 5% 1/4W
R680 1-216-073-00 RES,CHIP 10K 5% 1/10W
R681 1-216-049-91 RES,CHIP 1K 5% 1/10W
R682 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R683 1-216-025-91 RES,CHIP 100 5% 1/10W
R685 1-216-073-00 RES,CHIP 10K 5% 1/10W
R686 1-216-049-91 RES,CHIP 1K 5% 1/10W
R687 1-216-049-91 RES,CHIP 1K 5% 1/10W
R688 1-216-073-00 RES,CHIP 10K 5% 1/10W
R689 1-216-073-00 RES,CHIP 10K 5% 1/10W
R691 1-216-073-00 RES,CHIP 10K 5% 1/10W
R692 1-260-085-11 CARBON 68 5% 1/2W
R693 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R694 1-216-073-00 RES,CHIP 10K 5% 1/10W
R695 1-249-443-11 CARBON 0.47 5% 1/4W F
R696 1-216-633-11 METAL CHIP 180 0.50%1/10W
R697 1-216-649-11 METAL CHIP 820 0.50%1/10W
R698 1-216-073-00 RES,CHIP 10K 5% 1/10W
R699 1-216-081-00 RES,CHIP 22K 5% 1/10W
<RELAY>
RY601¡1-515-669-21RELAY
RY602¡1-755-031-11RELAY
<TRANSFORMER>
T601 ¡ 1-429-180-11 TRANSFORMER, LINE FILTER
T640 1-431-538-11 TRANSFORMER, CONVERTER (PIT)
T641 1-429-992-11 TRANSFORMER, CONVERTER (PRT)
T660 1-431-565-11 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR>
TH601 ¡1-809-260-11THERMISTOR, POWER
THP601¡1-809-827-11THERMISTOR, POSITIVE
<VARISTOR>
VDR601¡1-801-268-51VARISTOR TNR14V471K660
VDR602¡1-810-622-21VARISTOR
VDR640 1-810-974-21VARISTOR TNR10V431K660
********************************************************************************
* 8-933-311-00 D BOARD, COMPLETE
****************************
4-040-989-01 SPRING (A), TR RETAINER (IC702, R511)
4-040-992-01 SPRING (AA), TR RETAINER
(IC502, Q507)
4-040-994-01 SPRING (BB), TR RETAINER
(Q508, D519)
4-047-285-01 SHEET, INSULATING (Q909)
4-060-720-01 SHEET, INSULATE (Q508)
4-060-844-01 SHEET, INSULATING (IC702)
4-382-854-01 SCREW (M3X8), P, SW (+) (R937)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC702, Q704, Q706, Q908, Q909, R937)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
(IC502, Q507, Q508, D519, R511)
<CAPACITOR>
C001 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C003 1-163-019-00 CERAMIC CHIP 0.0068MF 10% 50V
C004 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
GD
7-7
To Next Page
