Sun Microsystems GDM-5510 Service Manual

GDM-5510 (E) 7
MODE AT PRODUCTION MODE 7 MODE 8 MODE 9 MODE 10
RESOLUTIION 1280 X 1024 1280 X 1024 1600 X 1200 1600 X 1200
CLOCK 135.000 MHz 216.000 MHz 202.500 MHz 202.500 MHz
– HORIZONTAL –
H-FREQ 81.130 kHz 120.941 kHz 93.750 kHz 93.750 kHz
usec usec usec usec
H. TOTAL 12.326 8.269 10.667 10.667
H. BLK 2.844 2.343 2.765 2.765
H. FP 0.237 0.120 0.316 0.316
H. SYNC 0.474 0.741 0.948 0.948
H. BP 2.133 1.481 1.501 1.501
H. ACTIV 9.481 5.926 7.901 7.901
– VERTICAL –
V. FREQ (HZ) 76.107 Hz 111.982 Hz 75.000 Hz 75.000 Hz
lines lines lines line
V. TOTAL 1066 1080 1250 1250
V. BLK 42 56 50 50
V. FP 2 1 1 1
V. SYNC 8 8 3 3
V. BP 32 47 46 46
V. ACTIV 1024 1024 1200 1200
– SYNC –
INT (G) NO NO NO NO
EXT (H/V)/POLARITY NO YES P/P YES P/P NO
EXT (CS)/POLARITY YES/N NO NO YES/N
INT/NON INT NON INT NON INT NON INT NON INT
2001.8.17 VER.
