1-2 Sun StorEdge 3000 Family FRU Installation Guide • May 2004
1.1 Available FRUs
Most FRUs are hot-swappable except a few modules which are hot-serviceable. Hot-
serviceable means that the module can be replaced while the RAID product and hosts
are powered up but the connected hosts must be inactive.
Caution – Please follow the FRU procedures carefully to ensure successful FRU
replacement.
The following tables list the FRUs that are currently available. For additional FRUs
and X-options, consult your sales representative or the latest Release Notes for Sun
StorEdge 3000 Family products on Sun web sites.
Caution – You can mix capacity in the same chassis, but not spindle speed (RPMs)
on the same SCSI bus. For instance, you can use 36 Gbyte and 73 Gbyte drives with
no performance problems if both are 10K RPM drives. Violating this configuration
guideline leads to poor performance.
TABLE 1-1 List of Available FRUs for the Sun StorEdge 3120 SCSI Array
FRU Model Number Description
F370-6195-xx 1U JBOD, LVD, Chassis + I/O board with SAF-TE
F370-6193-xx AC power supply and fan module, 1U
F370-6192-xx DC power supply and fan module, 1U
F370-5405-xx Cable, LVD, 1-foot, jumper
F370-5528-xx Cable, LVD, 1.5-foot, expansion
F540-6054-xx Drive module, 36 GB LVD, 10K RPM
F540-6055-xx Drive module, 36 GB LVD, 15K RPM
F540-6056-xx Drive module, 73 GB LVD, 10K RPM
F540-6057-xx Drive module, 73 GB LVD, 15K RPM
F540-6058-xx Drive module, 146 GB LVD, 10K RPM
XTA-3000-AMBS Air management blank sled
