User’s Manual - 15
Copyright(c) 2007, Sun Microsystems, Inc. All rights reserved.
Specification
Preset Timing Modes
Table 1. Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen
will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED
is
on. Refer to the video card manual and adjust the screen as follows.
Display Mode Horizontal
Frequ
ency
(kHz)
Vertical
Frequ
ency
(Hz)
Pixel Clock
(MH
z)
Sync Polarity
(H
/V)
VESA, 640 x 480
37.500 75.000 31.500 -/-
VESA, 640 x 480
37.861 72.809 31.500 -/-
VESA, 800 x 600
35.156 56.250 36.000 +,-/+,-
VESA, 800 x 600
37.879 60.317 40.000 +/+
VESA, 800 x 600
46.875 75.000 49.500 +/+
VESA, 800 x 600
48.077 72.188 50.000 +/+
VESA, 1024 x 768
48.363 60.004 65.000 -/-
VESA, 1024 x 768
56.476 70.069 75.000 -/-
VESA, 1024 x 768
60.023 75.029 78.750 +/+
VESA, 1280 x 1024
63.981 60.020 108.00 +/+
VESA, 1280 x 1024
79.976 75.025 135.00 +/+
SUN, 1152 x 900
The optimal resolution and only resolution recommended for this monitor is 1920x1200@60Hz. These
preset timing modes are offerred only to help assure that video will be displayed under most boot or
hot-plug conditions. It is recommended to change to 1920x1200@60Hz once video from the computer
system is seen on the display.
