Sunfire XTEQ8 - Product Specifications

18
User's Manual
User's Manual
MODEL XTEQ8 XTEQ10 XTEQ12
Driver Complement 8” Active Side
Firing Driver
8” Side Firing
Passive Radiator
10” Active Side
Firing Driver
10” Side Firing
Passive Radiator
12” Active Side
Firing Driver
12” Side Firing
Passive Radiator
Amplier Power 1,800 Watt
Tracking Down Converter
2,700 Watt
Tracking Down Converter
3,000 Watt
Tracking Down Converter
Frequency Response 22Hz – 100Hz 18Hz – 100Hz 16Hz – 100Hz
THD Less than
3% typical operation
Less than
3% typical operation
Less than
3% typical operation
High Pass Crossover 85Hz 85Hz 85Hz
Low Pass Crossover 30Hz 30Hz 30Hz
Phase 0 to 180 degree (variable) 0 to 180 degree (variable) 0 to 180 degree (variable)
Woofer Magnet 6.3” x 2.75” Deep
143 oz.
7.5” x 3.5” Deep
194 oz.
7.5” x 3.5” deep
194 oz.
Voice Coil 2” 3” 3”
Cone Material Non-pressed paper with a
high density foam edge
Non-pressed paper with a
high density foam edge
Non-pressed paper with a
high density foam edge
I
NPUTS
Line Level (L&R) Line Level (RCA)
Nominal Impedance 15k Ω
Line Level (RCA)
Nominal Impedance 15k Ω
Line Level (RCA)
Nominal Impedance 15k Ω
Input (Mono) Balanced (XLR)
Nominal Impedance 14k Ω
Balanced (XLR)
Nominal Impedance 14k Ω
Balanced (XLR)
Nominal Impedance 14k Ω
Slave Line Level - Mono (RCA)
Nominal Impedance 8k Ω
Line Level - Mono (RCA)
Nominal Impedance 8k Ω
Line Level - Mono (RCA)
Nominal Impedance 8k Ω
Microphone 3.5 mm
(condense mic incl.)
3.5mm
(Microphone included)
3.5mm
(Microphone included)
3.5mm
(Microphone included)
Trigger On (use ATMOS spee) 12 VDC 12 VDC 12 VDC
OUTPUTS
Thru (L&R) Line Level (RCA)
85Hz High Pass Filter /
Bypass - selectable
Line Level (RCA)
85Hz High Pass Filter /
Bypass - selectable
Line Level (RCA)
85Hz High Pass Filter /
Bypass - selectable
Slave Line Level – Mono (RCA)
Nominal Impedance 120k Ω
Line Level – Mono (RCA)
Nominal Impedance 120k Ω
Line Level – Mono (RCA)
Nominal Impedance 120k Ω
GENERAL
Finish High Gloss Black High Gloss Black High Gloss Black
Included Accessories Microphone and
Power Cord
Microphone and
Power Cord
Microphone and
Power Cord
Dimensions (H/W/D) - Net 9" x 9" x 9" 11" x 11" x 11.25" 13" x 13" x 12.25"
Weight Net 29 Lbs. 55 Lbs. 60 Lbs.
Power 100-120 / 220-240 V~,
50/60Hz, 900W
100-120 / 220-240 V~,
50/60Hz, 900W
100-120 / 220-240 V~,
50/60Hz, 900W
Specications
