25
The distance between the bottom of the inverter and the ground surface is deter-
mined according to the bending radius of the AC cable used and the installation
environment. In addition, the following conditions must be met:
• The distance between the bottom of the inverter and the ground surface is not
less 650 mm.
• The AC cable is vertically led into the cabinet, and the straight length is higher
than 200mm.
• If there are any questions, please consult the AC cable manufacturer.
In case of multiple inverters, reserve specific clearance between the inverters. For other in-
stallation scenarios, please refer to the relevant technical documents on
http://support.sun-
growpower.com/
.
In case of back-to-back installation, reserve specific clearance between the two inverters.
User Manual 4 Mechanical Mounting
