65
Step 7 Pull the cable gently to make sure it is secured, tighten the swivel nut clockwise.
- - End
5.13 Communication Module Connection (optional)
Connect the communication module produced by SUNGROW to the communication acces-
sory port. After successful connection, information such as power generation and running
state of the inverter can be viewed via the App on the phone.
*The image shown here is for reference only. The actual product you receive may differ.
Once the communication module is in use, do not connect the inverter to a 3rd
party data logger at the same time via RS485.
For details on module installation and configuration, refer to the manual delivered
together with the module.
User Manual 5 Electrical Connection
