User Manual 4 Unpacking and Storage
17
TUV mark of conformity.
The inverter is in compliance with directives of TUV.
CE mark of conformity.
The inverter is in compliance with directives of CE.
4.3 Delivery Contents
Fig. 4-3 Delivery Contents
*Images shown here is for reference only! Actual product you receive may differ.
It is used for mounting inverter onto the wall.
C Documents
Documents include quality certificate, packing list, product
test report, and quick user manual.
Six units. It is used for fastening backplate onto metal frame.
E Fix screws
2 M4×16 screws for fix the inverter to the backplate.
F
Eight pairs. PV input cables must be equipped with the
connector.
G
Eight pairs. Please insert MC4 cable gland to the
unconnected DC input terminal.
4.4 Storage of Inverter
Store the inverter properly when the inverter is not to be installed immediately.
Sungrow shall hold no liability for the corrosion of the device or the failure of device
