Sungrow SG5K-D User Manual

7 LCD Operation User Manual
68
The SPI remote control via RS485 connection to an external device
can also change the thresholds. When the local control and remote
control modes exist at the same time, the remote control takes priority
over the local control.

Sungrow SG5K-D Specifications

General

Rated AC Output Power	5000 W
Max. Efficiency	98.4%
Operating Temperature Range	-25°C to +60°C
Max. DC Power	6000 W
Number of MPPTs	2
Max. AC Power	5500 VA
Rated AC Voltage	230 V
AC Voltage Range	180 V - 280 V
Rated Grid Frequency	50 Hz / 60 Hz
Power Factor at Rated Power	>0.99
THDi	<3%
DC Connection Type	MC4
Protection Degree	IP65
Cooling Method	Natural convection
AC Connection Type	Plug-in terminal
