Sunny SF-E1405 - Parts List

4
PARTS LIST
NO
NAME
SPEC
QUANTIGY
1
LEFT HINGE BOLT
Φ16*112，1/2"
1
2
BUSHING 1
φ28*φ16*16
10
3
SPRING WASHER
φ20*φ13*2
2
4
LEFT LOCK NUT
1/2"
1
5
ADJUSTABLE END CAP
62*42
2
6
CARRIAGE BOLT
GB/T 12-1988 M10X62
4
7
REAR STABILIZER
PUNCHING
1
8
RIGHT LOCK NUT
1/2"
1
9
RIGHT HINGE BOLT
Φ16*112，1/2"
1
10
NYLON NUT
M8*9
4
11
FLAT WASHER
GB/T 95-2002 Φ8
4
12
CURVE WASHER
φ10*Φ25*1.5
4
13
DOMED NUT
GB/T 802-1988 M10
4
14
HEX HEAD BOLT 1
M8*50
4
15
END CAP 1
60*30*1.5
2
16
SCREW 1
GB/T 15856.1-2002 ST4.2X19
9
17
LEFT HANDLEBAR COVER (L)
99*80*39
1
18
BUSHING 2
φ18*φ10*10
4
19
LEFT PEDAL TUBE
WELDING
1
20
RIGHT HANDLEBAR COVER (L)
99*80*39
1
21
RIGHT PEDAL TUBE
WELDING
1
22
RIGHT HANDLEBAR COVER (R)
99*80*39
1
23
PEDAL
346*150*55
2
24
FRONT STABILIZER
PUNCHING
1
25
SCREW 2
GB/T 845-1985 ST4.2*19
6
26
HEX HEAD BOLT 2
M10*55
2
27
LEFT SWING BAR
WELDING
1
28
FRONT END CAP
Φ65*46
2
29
RIGHT SWING BAR
WELDING
1
30
HINGE SCREW
3/8"*20
2
31
SPRING WASHER
φ11.5*φ19.5*3
2
32
D SHAPE WASHER
δ5(φ28*5)
2
33
PLASTIC SLEEVE 1
Φ32*1.5
4
34
LOCKING KNOB
M8*38
4
35
WAVE WASHER
GB/T 955-1987
（d1=16 D=26 s=0.3)
4
36
MAIN FRAME
WELDING
1
37
FOAM GRIP
φ33*φ23*280
2
38
LEFT HANDLEBAR
WELDING
1
39
END CAP 2
25X1.5
2
40
RIGHT HANDLEBAR
WELDING
1
41
LEFT HANDLEBAR COVER (R)
99*80*39
1
42
SPINDLE BAR
Φ15.8*373(3/8")
1
43
WASHER (L)
Φ35*22.8*2
1
