Installation - Making Electrical Connections
26525-01A
Making Electrical Connections
2. Plug the three-prong 220V AC power
cord into a dedicated outlet (see Pre-
Installation Planning).
1. Connect the canopy to bench power
cord to the bench receptacle. The
plug is polarized. Align the terminals
and firmly push on until seated then
tighten the threaded locking ring.
THREADED
LOCKING RING
RECEPTACLE
ON BENCH
CANOPY TO BENCH
POWER CORD
WARNING
Shock hazard.
Be sure AC power is disconnected
before connecting cables.
