7 Display and messages
35
3
Pin1:0000 W
Pin2:0000 W
Pin1: Input power of channel 1
Pin2: Input power of channel 2
Pin:0000 W
In a configuration with one input connected and
a second input connected in parallel, this screen
is shown instead of the screen described in
3
.
4
Vgrid: 000 V
Igrid: 00.0 A
Vgrid: Grid voltage
Lgrid: Grid current
5
Pout:0000 W
Fgrid:000.0 Hz
P-out: Output power
Fgrid: Grid frequency
6
GFCI: 0000 mA
GFCI: Leakage current of the system
2. Statistics
This submenu mainly contains some Statistics
data of the inverter. The screens may be scrolled
manually by pressing the
- and -keys. And
you can call back the previous menu by pressing
the
ESC
-key.
T-day:000.0 h
E-day:000.0 KWh
T-day:
Today’s lifetime counter of energy transferred to
the grid.
E-day: Today’s energy transferred to the grid.
T-mon:000.0 h
E-mon:000.0 KWh
T-mon:
This month’s lifetime counter of energy trans-
ferred to the grid.
E-mon:
This month’s energy transferred to the grid.
T-tot:000.0 h
E-tot:000.0 KWh
T-tot:
Total lifetime counter of energy transferred to
the grid.
E-tot: Total energy transferred to the grid.
Setting Menu
Select “Settings” from the Main menu to display the
first screen that refers to the password:
Password
0000
Default password is “0000”.
NOTE
Can’t enter settings menu when communication is
abnormal. Running state no setting allowed.
Operation guide
· Use the
OK
-key to move from one figure to the
next (from left to right)
· Use the
ESC
-key to go back to quit password input
and go back to the previous menus.
· Press the
-key to scroll numbers backwards
(from 0 to 9).
To Next Page
