10.2 NTX wiring diagrams
NTX connections for 208 V and 240 V AC grids
AC Switch
PV
Array
Equipment
Ground
PV+
PV–
PV+
PV–
N
L1 L2 PE
OFF
Breaker
Size
2p 50 Amp
AC
Distribution
Panel
Earth Ground
Utility
ON
L1 L2
Main
Ground
Neutral
NTX connections for 277 V AC grids
AC Switch
PV
Array
Equipment
Ground
PV+
PV–
PV+
PV–
N
L1 L2 PE
OFF
Breaker
Size
1p 40 Amp
AC
Distribution
Panel
Earth Ground
Utility
ON
L1 L2
Main
Ground
Neutral
