10 Technical data
49
Nominal voltage Trip limit Trip voltages
line to neutral
Trip voltages
line to line
Trip times
208 V
50% Adjustable
52.0 V~98.8 V
(default 52.0 V)
Adjustable
104.0 V ~197.6 V
(default 104.0 V)
0.01 s
88% Adjustable
57.2 V~98.8 V
(default 91.5 V)
Adjustable
114.4 V~197.6 V
(default 183.0 V)
Adjustable
0.16 s~10 s
(default 1.67 s)
110% Adjustable
109.2 V~119.6 V
(default 114.4 V)
Adjustable
218.4 V~239.2 V
(default 228.8 V)
Adjustable
0.16 s~10 s
(default 0.83 s)
120% Adjustable
109.2 V~124.8 V
(default 124.8 V)
Adjustable
218.4 V~249.6 V
(default 249.6 V)
0.01 s
240 V
50% Adjustable
60.0 V~114.0 V
(default 60.0 V)
Adjustable
120.0 V~228.0 V
(default 120.0 V)
0.01 s
88% Adjustable
66.0 V~114.0 V
(default 105.6 V)
Adjustable
132.0 V~228.0 V
(default 211.2 V)
Adjustable
0.16 s~10 s
(default 1.67 s)
110% Adjustable
126.0 V~138.0 V
(default 132.0 V)
Adjustable
252.0 V~276.0 V
(default 264.0 V)
Adjustable
0.16 s~10 s
(default 0.83 s)
120% Adjustable
126.0 V~144.0 V
(default 144.0 V)
Adjustable
252.0 V~288.0 V
(default 288.0 V)
0.01 s
