PRESSURE SENSORS
DP5/DPH
Head-separated
DP4
DP2
DP3
DP-M
Digital Display
PE
LED Bar Display
DP4
788
PRECAUTIONS FOR PROPER USE
DIMENSIONS (Unit: mm in) The CAD data in the dimensions can be downloaded from the SUNX website: http://www.sunx.co.jp/
DP4-5
Sensor
MS-DP-2
DIN rail mounting bracket (Optional)
Piping
• When connecting a commercial M5 coupling to the
pressure port, hold the flat sides of the pressure port with
a 13 mm 0.512 in spanner and make sure that the
tightening torque is 1Nm or less.
If excessive tightening torque is applied, the commercial
fitting may break.
Mounting
• Install the enclosed panel mounting bracket (MS-DP-1) as
shown in the figure below.
The tightening torque should be 0.15 Nm or less. Further,
tighten both the right and the left screw gradually and
equally, so that the panel mounting bracket does not tilt.
13 mm 0.512 in
spanner
M3 (length 15 mm 0.591 in)
panel fixing screw (Accessory)
Panel mounting bracket
(MS-DP-1)(Accessory)
7
0.276
42
1.654
29
1.142
3
1
/2 digit LCD display
(Green and red)
Decrement key
Increment key
Mode selection key
40
1.575
20
0.787
M5 female thread
Connector
36.5
1.437
(5)
(0.197)
DOWN
MODE
UP
2
0.079
40
1.575
42
1.654
(10)
(0.394)
20
0.787
20
0.787
15
0.591
13
0.512
52
2.047
3
0.118
40
1.575
9
0.354
6
0.236
DOWN
MODE
UP
Variable range
2-"4.5 "0.177
mounting holes
Suitable for
35 mm 1.378 in
width DIN rail
Assembly dimensions
<Horizontal mounting><
Vertical mounting>
3
0.118
52
2.047
49
1.929
(10)
(0.394)
40
1.575
9
0.354
6 0.236
20
0.787
2.9
0.114
35
1.378
40
1.575
15
0.591
13
0.512
DOWN
MODE
UP
Variable range
Suitable for
35 mm 1.378 in
width DIN rail
2-"4.5 "0.177
mounting holes
