SPECIFICATIONS
PERFORMANCE
Model 90084
Max Gallons Per Hour 3200
Volts 120
Amps 1.8
Hz 60
Watts 100
Max Height 19 ft.
Discharge Size 1.85 in.
Liquid Temp. Range 34°F to 120°F
Cord Length 16 ft.
Pump Housing Construction Thermoplastic
Drive Type Magnetic
Removable Filter Yes
Adapters Included ∙ 1-1/2 in. Outlet Nut and Gasket
∙ 2 in. Outlet Nut
∙ 1 in. x 1-1/4 in. x 1-1/2 in. BARB
∙ 1-1/2 in. x 2 in. BARB outlet
Model 0 ft. 4 ft. 8 ft. 12 ft. 16 ft. Max Lift
90084 3200 2750 1500 1000 560 19 ft
Gallons per hour at discharge height.
0 500 1000 1500 2000 2500 3000 3500
0 ft.
5 ft.
10 ft.
15 ft.
20 ft.
90084
Model Number
GALLONS PER HOUR
DISCHARGE HEIGHT
Height and/or piping restriction will reduce the pump output performance. It is recommended to use the same
size or larger pipe as the pump discharge for optimum performance.
This Submersible Pond Pump is designed to circulate water throughout ponds and water features.
DESCRIPTION
