Wall
CLEARANCES
Minimum clearances to combustibles for the
replace are as follows:
*Back and sides 1"
Perpendicular walls 6"
Floor 0"
Ceiling to louver opening 42"
Front 36"
Top of Standoffs 0"
Vent (See venting instructions
for specic venting
clearances.)
Combustible material with a maximum thick-
ness of 5/8" may be ush with the top front
of replace.
* For back and sides of replace, do not pack
with insulation or other materials. 1" clearance
not required at nailing anges.
NOTICE: This replace is intend-
ed for use as supplemental heat.
Use this replace along with
your primary heating system.
Do not install this replace as
your primary heat source. If you
have a central heating system,
you may run system’s circulat-
ing blower while using replace.
This will help circulate the heat
throughout the house.
FRAMING AND FINISHING
Figure 5 shows typical framing of this re-
place. Figure 6 shows framing for corner
installation. All minimum clearances must
be met.
If you are using a separate combustible man-
tel piece, refer to Figure 7 for proper instal-
lation height. You can install noncombustible
mantels at any height above the replace.
Note: Noncombustible mantels may discolor!
PRE-INSTALLATION
Continued
Figure 5 - Framing Clearances with
Outside Air Flex Duct
Figure 6 - Framing Clearances for Corner
Installation
Figure 7 - Clearances for Combustible
Mantels
Ref.
Mantel
Depth Ref.
Mantel from
Top of Opening
1 14" A 16"
2 12" B 14"
3 10" C 12"
4 8" D 10"
5 6" E 8"
6 4" F 6"
7 2" G 4"
36
3
/
8
" (36")
43
3
/
8
" (42")
43" (36"), 50" (42")
41" (36"), 48" (42")
15
3
/
4
" (36")
19" (42")
51
3
/
8
" (36")
61
3
/
4
" (42")
Nailing
Flange
Maintain 1'' Clearance at Sides
and Back of Fireplace
44
"
(36")
48
"
(42")
41 " (36")
48
" (42")
