KEY
NO. PART NO. DESCRIPTION QTY.
1 122839-02 Burner Tube, 36" • • 1
122839-01 Burner Tube, 42" • • 1
2 ** Front Burner Assembly • • • • 1
3 112371-15 Rear Orice, #47 NG • 1
23100 Rear Orice, #56 Propane/LP • 1
23101 Rear Orice, #44 NG • 1
23567 Rear Orice, #55 Propane/LP • 1
4 11214 Bulkhead Fitting • • • • 2
5 116573-01 Washer, Flt 7/8"x1
1
/
4
" OD • • • • 5
6 ** Log/Burner Base • • • • 1
7 122122-01 Pilot, NG • • 1
122122-02 Pilot, Propane/LP • • 1
123783-01 Pilot, NG High Altitude 1
8 ** Pilot Shield • • • • 1
9 14296 Elbow, Street 3/8" • • • • 1
10 112371-15 Front Orice, #47 NG • 1
23100 Front Orice, #56 Propane/LP • 1
24771 Front Orice, #42 NG • 1
23100 Front Orice, #56 Propane/LP • 1
11 ** Base • • • • 1
12 114027-01 Grommet SC 1/2" ID 1
1
/
16
" OD • • • • 1
13 14399 90° Elbow, Brass 3/8" Tube x 3/8" NPT • • • • 2
14 111817-06 Flextube Dormont, 3/8" Dia. x 11" • • • • 1
15 111817-09 Flextube Dormont, 3/8" Dia. x 24" • • • • 1
16 ** Pilot Bracket • • • • 1
17 122116-01 Dexen Valve, NG • • 1
122117-01 Dexen Valve, LP • • 1
123782-01 Dexen Valve, NG High Altitude 3.8" 1
18 112823-01 Brass T-Fitting 3/8" • • • • 1
19 122118-01 Control Module • • • • 1
20 122119-01 Battery Relay • • • • 1
21 122121-01 Battery Pack • • • • 1
22 122860-01 Valve Bracket • • • • 1
23 125243-01 Remote Control Kit • • • • 1
24 ** Log Assembly, 36" • • 1
** Log Assembly, 42" • • 1
25 123560-01 Base Valve • • • • 1
PARTS AVAILABLE NOT SHOWN
122120-01 Wire Harness Relay • • • • 1
122123-01 AC Adapter 3V • • • • 1
112799-01 Ember Flakes Kit • • • • 1
26839 Rockwool • • • • 1
GA6060 Lave Rock Kit • • • • 1
VTA-LS5-2 Log Scrap Kit • • • • 1
14253 30" Flex Line • • • • 1
PARTS
BURNER ASSEMBLY
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 39 of this manual. This table uses catalog
numbers for clarity on models.
F1322/F1323
F1324/F1325
F1326/F1327
F1328/F1329
To Next Page
