NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
H2262 SV8SU Support Strap
H2263 SV8SP Support Plate
H3908 SV8ARSA Attic Insulation Shield
(adjustable 12” to 22”)
J7422 810360-13 Barrier Kit
H8315 SG22 Barrier Kit (Outdoor)
INSTALLATION ACCESSORIES
Listed Secure Vent™ Components
Cat.
No.
Model
No.
Description
H8323 SV8HTS4 Horizontal Square
Termination with
Firestop/Spacer
(H8322) and
Adaptor (H2267)
H2265 SV8VTR Vertical Termination
H2250 SV8L6 6 inch (152 mm)
Vent Section
H2251 SV8L12 12 inch (305 mm)
Vent Section
H2252 SV8L24 24 inch (610 mm)
Vent Section
H2253 SV8L36 36 inch (914 mm)
Vent Section
H2254 SV8L48 48 inch (1219 mm)
Vent Section
H2255 SV8LA Telescopic Section
H2256 SV8E45 45 Degree Elbow
H2257 SV8E90 90 Degree Elbow
The following flashings come packaged with
a storm collar
H3236 SV8F Flat Roof Flashing
H2258 SV8FA Adjustable Flashing,
1/12 to 7/12
H2259 SV8FB Adjustable Flashing,
7/12 to 12/12
H3237 SV8SC6 Storm Collar
(pkg of 6)
H8322 SV8HF4 Firestop/Spacer,
Horizontal
(4-1-1 spacing)
H2261 SV8BF Firestop/Spacer,
Vertical
(1-1-1 spacing)
