INNOVATIVE HEARTH PRODUCTS • SEE-THROUGH DIRECT-VENT GAS FIREPLACES (DRT63STTEN/P) • INSTALLATION INSTRUCTIONS
Classic Screen Kits
These decorative freestanding firescreen pan-
els are designed to enhance the beauty of the
fireplace and create a barrier to prevent direct
contact with the hot glass.
Arch Screen Kits
These decorative freestanding firescreen pan-
els are designed to enhance the beauty of the
fireplace and create a barrier to prevent direct
contact with the hot glass.
Dual Arch Screen Kits
These decorative freestanding firescreen pan-
els are designed to enhance the beauty of the
fireplace and create a barrier to prevent direct
contact with the hot glass.
Barrier Kits
These screen kits create a barrier to prevent di-
rect contact with the hot glass. The screen panel
affixes directly to the front glass enclosure panel.
Dual Arch Screen Kits
Cat. No. Model Description
H5051 DASK-LSM40-2 Dual Arch Screen
Classic Screen Kits
Cat. No. Model Description
H5052 SK-LSM40-2 Classic Screen Kit
Arch Screen Kits
Cat. No. Model Description
H5053 ASK-LSM40-2 Arch Screen Kit
Barrier Kits
Cat. No. Description
J7422 Barrier
H8249 Barrier (Outdoor)
Outdoor Kit
When installing this appliance in an indoor / out-
door configuration, this outdoor kit is required
to be installed on the outdoor side.
Outdoor Kit
Cat. No. Model Description
H7940 LSM40STODK Outdoor Kit
(light-tint glass)
H8061 LSM40ST-ODKT Outdoor Kit
(dark-tint glass)
