LAN Port Enable/Disable
Use jumper JPL1 to enable or disable LAN ports 1 and 2. See the table below for
jumper settings. The default setting is Enabled.
LAN Port Enable/Disable
Jumper Settings
Jumper setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled
2-4 Jumpers
Explanation of Jumpers
To modify the operation of the add-on card, a jumper can be used to choose between
optional settings. A jumper creates shorts between two pins to change the function
of the connector. Pin 1 is identied with a square solder pad on the printed circuit
board. See the add-on card layout on page 2-2 for the jumper location.
Note: On two-pin jumpers, "Closed" means the jumper is on and "Open"
means the jumper is off the pins.
Thermal Alert
PinDenition
Pin Denition
1 GND
2 Thermal_Alert_N
3 GND
Thermal Alert Connector
Connect an external cable (not included) from the motherboard to the thermal alert
connector at JP3 to monitor the external temperature. Refer to the table on the right
for the pin denition. Refer to page 2-2 for the location of the jumper.
