Supermicro AOC-MTGN-i2S - Before and During Installation

3-2
AOC-MTG-i2S Add-on Card User's Guide
3-2 Before Installation
To install the add-on card properly, be sure to follow the instructions below.
1. Power down the system.
2. Remove the power cord from the wall socket.
3. Use industry standard anti-static equipment such as gloves or wrist strap and
follow the precautions listed on page 3-1 to avoid damage caused by ESD.
4. Familiarize yourself with the server, motherboard, and/or chassis documenta-
tion.
5. Conrm that your operating system includes the latest updates and hotxes.
3-3 Installing the Add-on Card
Follow the steps below to install the add-on card into your system.
1. Remove the server cover and, if any, set aside any screws for later use.
2. Remove the add-on card slot cover. If the slot cover has a screw, place it
aside for later use.
3. Position the add-on card in front of the SIOM slot and gently push in both
sides of the card until it slides into the slot.
SIOM card with the
bracket installed
Insert the SIOM
card into this slot
Note: This add-on card does not support hot plug. Please turn off the AC
power and remove the power cord from the wall socket before you install
or remove the add-on card.
