2-3 Connectors and LEDs
LAN Ports
Two SFP+ LAN ports (LAN1 and LAN2) are located on the add-on card. These
LAN ports support connection speeds of 10Gbps. Use SFP+ direct attach twinaxial
copper cables for network connections.
LED Color Denition
LNK
Yellow 1Gb Link Speed
Green 10Gb Link Speed
ACT
Blinking Green Activity
LED1 and LED2
Each LAN port has a corresponding LED to indicate speed and data activity. LED1
is for LAN port 1 and LED2 is for LAN port 2. For the location of the LEDs, see the
card layout on the previous page. For LED color and denition, see the table below.
Thermal Alert LED
A thermal alert LED is located at LED3. The yellow LED indicates there is a thermal
alert. Refer to the table on the right for the LED status. Refer to page 2-2 for the
location of the LED.
Thermal Alert
LED Status
Color Status
Yellow Thermal Alert
