Supermicro AOC-S100GC-i2C User Manual

Chapter 2: Hardware Components
2-5
REV:1.02
AOC-S100GC-i2C
DESIGNED IN USA
LED1
LED2
J4
JP2
PORT1 PORT2
JNCSI1
JP4
JP1
1
3
1
2
1
1
2-5 Jumper Settings
Explanation of Jumpers
To modify the operation of the mother-
board, jumpers can be used to choose
between optional settings. Jumpers create
shorts between two pins to change the
function of the connector. Pin 1 is identied
with a square solder pad on the printed
circuit board. See the motherboard layout
pages for jumper locations.
1. JP1
2. JP2
3. JP4
Connector
Pins
Jumper
Cap
Setting
Pin 1-2 (Short)
1 2 3
1 2 3
Note: JP1 is for production use only.
