Chapter 1: Introduction
Chapter 1
Introduction
1.1 Overview
This chapter provides an outline of the functions and features of the SuperServer
System Overview
Motherboard
H13SSW
Chassis
CSE-LA26TS-R1K23AWP1
Processors
Single AMD EPYC™ 9004 Series Processor in SP5 socket
Memory
12 DIMM slots up to 3TB registered ECC DDR5 4800MT/s speed
Storage
12 3.5"/2.5" hot-swap hybrid SATA/NVMe*/SAS* drive bays (*requires additional parts)
Two Gen 3 M.2 NVMe PCIe 3.0 x2 SSDs for boot drive
Expansion Slots
Two PCIe 5.0 x16 FHFL*
Two PCIe 5.0 x16 FHHL
Two PCIe 5.0 x8 FHFL(Optional)**
*With 12 NVMe, only one FHFL is available.
** PCIe Slots 2 and 4 are not available with NVMe drive option
I/O Ports
Two AIOM network modules, PCIe 5.0 x16 (OCP 3.0 NIC)
One dedicated LAN port
Two USB 3.0 ports (rear)
One VGA port (rear)
One serial port (rear)
System Cooling
Three counter-rotating fans with optimal fan speed control
One air shroud
Power
Two 1200W redundant power supplies, 80Plus Titanium level*
Form Factor
2U; 17.2” x 3.5” x 25.5” (depth) (43.7 x 8.9 x 64.8 cm)
A Quick Reference Guide can be found on the product page of the Supermicro website.
compliant with UL or CSA: LA26CDC-R8H13, LA26CDC-R12H13, LA26-R16H13, LA26CDC-
R11DH13, LA26-8, LA26-12,LA26-16, LA26-11D.
Network Connection Options
include RJ45, SFP+, QSFP28, etc. at 1/10/25/100GbE capabilities, with two or four ports per
module, up to two modules. See the web product page for current choices. At supermicro.
com, search for the product by model number.
