14
H11SSL Motherboard Series User's Manual
Connector Description
JSTBY1 Stand by power header
JIPMB1 4-pin BMC external IC header
JPWR2 24-pin ATX power supply connector
JPWR1 12V 8-pin ATX CPU power connector
JPW1 4-pin ATX auxiliary power supply connector
JD1 Front panel external speaker header
PWRI2C Power supply SMBus I2C header
LAN1, LAN2 Back panel LAN1, LAN2 connectors
VGA Back panel VGA port
SP1 Onboard speaker
Note: Jumpers, connectors, switches, and LED indicators that are not described in the
preceding tables are for manufacturing testing purposes only, and are not covered in this
manual.
