Chapter 1: Introduction
1-5
P4SPA+/P4SPE Quick Reference
Jumpers Description Default Setting
JBT1 CMOS Clear See Section 2-7
JP1 Overheat Fan Force-On Open (Disabled)
JP2, JP3 FSB Speed Pins 1-2 (Auto)
JP4 Watch Dog Pins 2-3 (NMI)
JP20 Force Power-On Open (Disabled)
JPUSB USB Wake Up (USB0/1) Pins 1-2 (Disabled)
JPWAKE KB/Mouse Wake-Up Pins 1-2 (Disabled)
Connectors Description
AUX Auxiliary Port Connector
CD1 Audio CD Input (large connector)
COM1 COM Port/Serial Port 1 Connector
COM2 COM Header/Serial Port 2 Header
Chassis Fan 1 Chassis Fan Header
CPU Fan Processor Fan Header
OH Fan Overheat Fan Header
DIMM1/2/3/4 Memory (DIMM) Slots (1 through 4)
Ethernet Gigabit LAN (Ethernet Port)
Floppy Connector(1) Floppy Disk Connector
Game Port Game Port
IDE(2) 2 IDE Connectors
SATA 2 SATA Headers
J1 PS/2 Keyboard/Mouse
J4 Parallel Printer Port
J7 ATX Power Connector
J9 12V Power Supply
JF1 Front Control Panel
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JWOR Wake-On-Ring Header
LINE IN Audio In Connector
LINE OUT Audio Out (Speaker) Connector
MIC Microphone Input
USB 0/1/2/3/4/5/6/7 Universal Serial Ports 0-7
VGA Video/Graphic Connector
WOL Wake-On-LAN
*Note: The onboard VGA and G-LAN connections are available for the P4SPA+ only.
