Chapter 2: Installation
2-13
USB Wake-Up
Use JPUSB to enable or disable USB
Wake-Up, which allows you to wake
the system up by pressing a key on
the keyboard or by clicking the mouse
when it is connected to the USB0
or USB1 port. This jumper is used
together with the USB Wake-Up func-
tion in the BIOS. Enable both jumper
setting and the BIOS setting to allow
the system to be awakened. See the
table on the right for jumper settings.
Jumper
Position
1-2
2-3
Definition
Disabled
Enabled
USB Wake-Up
Jumper Settings
(JPUSB)
Watch Dog Enable/Disable
JP4 enables the function of Watch
Dog. Watch Dog is a system monitor
that takes actions when a software
application freezes the system. Close
pins 1-2 to reset the system if a pro-
gram freezes. Close pins 2-3 to gen-
erate a non-maskable interrupt for the
program that freezes. See the table
on the right for jumper settings. Watch
Dog must also be enabled in BIOS.
Jumper
Position
Pins 1-2
Pins 2-3
Open
Definition
WD to Reset
WD to NMI
Disabled
Watch Dog
Jumper Settings (JP4)
JP2
1-2
NC
Front Side Bus Speeds:
JP2, JP3
Reserved
JP3
1-2 AUTO
2-3 2-3
100 MHz
2-3 133 MHz
NC
NC
NC
2-3 200 MHz
Front Side Bus Speed
Settings
JP 2 and JP3 are the jumpers for the
Front Side Bus Speed Select. See the
table on the right for pin defi nitions.
