UPER P4SPA+/P4SPE User's Manual
Pin
Number
1
2
3
Definition
+5V Standby
Ground
Wake-up
Wake-On-LAN Pin
Definitions (WOL)
Wake-On-LAN
The Wake-On-LAN header is des-
ignated WOL on the motherboard.
See the table on the right for pin
defi nitions. You must enable the LAN
Wake-Up setting in the BIOS to use
this function. (You must also have a
LAN card with a Wake-On-LAN con-
nector and cable to use this feature.)
Universal Serial Bus (USB)
In addition to the Back Panel USB
ports, USB 6 and USB 7 are Univer-
sal Serial Bus headers that can be
used to provide front side chassis
access (cables not included). See
the tables on the right (below) for pin
defi nitions.
Pin# Definition
1 +5V
2 P0-
3 P0+
4 Ground
Pin
Number
2
4
6
8
10
Definition
+5V
PO-
PO+
Ground
Ground
Pin
Number
1
3
5
7
Definition
+5V
PO-
PO+
Ground
USB Pin Definition
J11
JPUSB
ATX PS/2 Keyboard and
PS/2 Mouse Ports
The ATX PS/2 keyboard and the PS/2
mouse are located at J1. See the table
on the right for pin defi nitions. (The
mouse port is above the keyboard
port.)
PS/2 Keyboard
and Mouse Port
Pin Definitions
(J1)
Pin
Number
1
2
3
4
5
6
Definition
Data
NC
Ground
VCC
Clock
NC
