X9SRi/X9SRE Motherboard Series User’s Manual
Keyboard/Mouse
One (1) PS/2 KB/Mouse combo port on the I/O backpanel
Serial (COM) Ports
Two (2) Fast UART 16550 connections: one 9-pin RS-232
port (Backpanel COM1 port) and one header (COM2)
Super I/O
Winbond Super I/O NCT6776F
BIOS 64 Mb SPI AMI BIOS
®
SM Flash BIOS
Play and Plug APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0/2.0,
USB Keyboard and SMBIOS 2.3
Power Conguration ACPI/ACPM Power Management
Wake On LAN (WOL) Header
Keyboard Wake-up from Soft-Off
CPU Fan Auto-off in Sleep Mode
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for CPU core, +3.3V, VDIMM,
CPU VTT, +5V, +3.3V Stdby, VBAT
CPU 6-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
CPU & Chassis Environment
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 2.0
support
System resource alert via Supero Doctor III
SuperDoctor
®
III, Watch Dog, NMI
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel® C204 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
Dimensions ATX form factor (12" x 9.6")
Note: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
