Chapter 1: Introduction
1-7
Motherboard Features
CPU Single Intel® E5-1600/E5-2600 series processor (LGA
2011 pin, Socket-R)
Memory Eight (8) DIMM slots support up to 256GB of DDR3, ECC
RDIMM memory or 64GB of DDR3 Unbuffered, non-ECC
UDIMM memory, up to 1600MHz..
Supports dual-channel memory bus
DIMM sizes
UDIMM 1GB, 2GB, 4GB, 8GB
RDIMM/LRDIMM 2GB, 4GB, 8GB, 16GB, 32GB
Chipset Intel® C606 or C602
Expansion Slots X9SRE Series Only (optimized for 3U/4U chassis)
Three (3) PCI-X 64-bit Slots
One (1) PCI-Express 3.0 x16 Slot
One (1) PCI-Express 3.0 x8 in x16 Slot
One (1) PCI-Express 2.0 x4 in x16 Slot
X9SRi Series Only (optimized for 1U/2U chassis)
One (1) PCI-Express 3.0 x16 Slot
One (1) PCI-Express 3.0 x8 in x16 Slot
One (1) PCI-Express 2.0 x4 in x16 Slot
Integrated Graphics Matrox® G200eW (on BMC controller)
Network Connections Two (2) Intel Powervill Gbit LAN Ports
I/O Devices SAS/SATA Connections
SAS Ports Eight (8)
3 Gb/s
(on "3F" models only) RAID 0, 1, 10, 5 (option)
SATA 3.0 Ports Two (2)
6 Gb/s RAID 0, 1, 5, 10
SATA 2.0 Ports Four (4)
3 Gb/s
Integrated IPMI 2.0 (X9SRi-F, X9SRi-3F, X9SRE-F, and
X9SRE-3F Only)
IPMI 2.0 supported by the WPCM450 Server BMC
USB Devices
Two (2) USB ports on the rear I/O panel
Six (6) USB headers for front access
One (1) Type A internal connectors
