Supermicro X11SSH-CTF User Manual

14
X11SSH-CTF/TF User's Manual
Connector Description
JSD1/JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID Switch
LAN1/LAN2 LAN (RJ45) Ports
SLOT4 PCH PCI-E 3.0 X2 (IN X4) Slot
SLOT6 CPU PCI-E 3.0 X8 Slot
SP1 Internal Speaker/Buzzer
USB0/1 Back panel Universal Serial Bus (USB) 2.0 Port
USB2/3, USB4/5 Front Accessible USB 2.0 Headers
USB6/7 Back panel USB 3.0 Port
USB8 USB Type A Header
USB9/10 Front Accessible USB 3.0 Header
VGA VGA Port

Supermicro X11SSH-CTF Specifications

General

Brand	Supermicro
Model	X11SSH-CTF
Category	Motherboard
Language	English
