Motherboard Features
CPU
• Single Intel® E3-1200 v5, 6th Gen Core i3, Pentium, and Celeron series processor in an LGA1151 socket
Memory
• Integrated memory controller supports up to 64 GB of DDR4 ECC UDIMM 2133MHz memory in four DIMM slots.
DIMM Size
• 4GB, 8GB, 16GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel® PCH C236
Expansion Slots
• One (1) PCI Express 3.0 X2 (IN X4) slot (PCH Slot4)
• One (1) PCI Express 3.0 X8 slot (CPU Slot6)
Network
• Intel® X550 10G Ethernet Network Controller
BaseBoard Management Controller (BMC)
• ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
• One (1) Dedicated IPMI LAN located on the rear IO back panel
Graphics
• Graphics controller via ASpeed 2400 BMC
• Intel IGD
I/O Devices
• Serial (COM) Port
• One (1) Fast UART 16550 port on the I/O back panel
• One (1) serial-port header
• SATA 3.0 • Eight (8) SATA 3.0 ports supported by Intel PCH (I-SATA 0-7)
• RAID (PCH) • RAID 0, 1, 5, 10
• SAS 3.0 (X11SSH-CTF only) • Eight (8) SAS 3.0 connections via LSI3008 with two mini-SAS HD (SAS 0-7)
• RAID (LSI3008) • RAID 0, 1, 10
