Super X12STL-IF User's Manual
Note: Table is continued on the next page.
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled)
JPL2 LAN2 Enable/Disable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JRF1 CPU PCIe Bifurcation
Pins 1-2 (JPCIE x16)
Pins 2-3 (JPCIE 2 x8)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
LED Description Status
LED1 Onboard Power LED Solid Green: Power On
LED2 UID LED Solid Blue: Unit Identied
LED3 OH LED Solid Red: Overheat
LEDM1 BMC Heartbeat LED Blinking Green: Device Working
Connector Description
BMC_LAN Dedicated BMC LAN Port
BT1 Onboard Battery
COM1 COM Port
FAN1 - FAN3, FANA System Fan Headers (FAN1: CPU Fan)
I-SATA0-3 Intel PCH SATA 3.0 Ports
I-SATA4, I-SATA5 Intel PCH SATA 3.0 Ports
JD1 Speaker/Buzzer
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JMD1 M.2 PCIe 3.0 x4 (supports 2280 form factor)
JMD1_SRW1 M.2 Holding Screw
JPI2C1 Power I
2
C System Management Bus (Power SMB) Header
JPWR1 24-pin ATX Power Connector
JPV1 4-pin Power Connector
JSD1, JSD2 SATA DOM Power Connectors
JSMB1 System Management Bus Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID Switch
LAN1/2 Gigabit Ethernet RJ45 Ports
MH1 - MH4 Mounting Holes
SLOT7 PCIe 4.0 x16 Slot (SLOT7 will run at PCIe 3.0 x16 when a Pentium processor is installed)
