Motherboard Features
CPU
• Supports an Intel Xeon E-2300 and 10th Generation Pentium (Socket H5 - LGA 1200) series processor with up to eight
cores
Memory
• Up to 64GB of DDR4 ECC UDIMM memory with speeds of up to 3200MHz in two memory slots
Note: Speed support is up to 2666MHz when a Pentium processor is installed. Speed support is up to 2933 MT/s
for 2R2R congurations.
DIMM Size
• 4GB, 8GB, 16GB, 32GB at 1.2V
Note: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel C252
Expansion Slots
• One PCIe 4.0 x16 Slot (It will run at PCIe 3.0 x16 when a Pentium processor is installed)
• One M.2 PCIe 3.0 x4 Slot (supports M-Key 2280)
Network
• Intel I210-AT Gigabit Ethernet Controller
Super I/O
• Aspeed AST2600
I/O Devices
• One COM port (COM1)
• Six SATA 3.0 ports at 6 Gb/s
• One VGA port on the rear I/O panel
Peripheral Devices
• Two USB 2.0 ports on the rear I/O panel (USB0/1)
• One front accessible USB 2.0 header with two USB connections (USB2/3)
• Two USB 3.2 ports on the rear I/O panel (USB4/5)
• One front accessible USB 3.2 header with two USB connections (USB6/7)
BIOS
• 512Mb AMI BIOS
®
SPI Flash BIOS
• ACPI 6.0, Plug and Play (PnP), BIOS rescue hot-key, and SMBIOS 3.0 or later
Motherboard Features
