15
Chapter 1: Introduction
Motherboard Features
Power Management
• ACPI power management
• Power button override mechanism
• Power-on mode for AC power recovery
• Wake-on-LAN
System Health Monitoring
• Onboard voltage monitoring for +12V, +5V, +3.3V, CPU, Memory, VBAT, +3.3V stdby, CPU temperature, PCH temperature,
system temperature
• 6 CPU switch phase voltage regulator
• CPU thermal trip support
• Platform Environment Control Interface (PECI)/TSI
Fan Control
• Fan status monitoring
• Dual cooling zone
• Four 4-pin fan headers
System Management
• Trusted Platform Module (TPM) support
• SuperDoctor® 5
• Chassis intrusion header and detection
LED Indicators
• CPU/System Overheat LED
• Power/Suspend state LED
• Fan Fail LED
• UID/Remote LED
• LAN Activity LED
• HDD Activity LED
Dimensions
• mini-ITX, 6.7" (W) x 6.7" (L) (193.04mm x 193.04mm)
Note: The CPU maximum thermal design power (TDP) is subject to chassis and
heatsink cooling restrictions. For proper thermal management, please check the chas-
sis and heatsink specications for proper CPU TDP sizing.
