17
Chapter 1: Introduction
1.2 Processor and Chipset Overview
Built upon the functionality and capability of the Intel Xeon E-2300 and 10th Generation
Pentium (Socket H5 - LGA 1200) series processor and the Intel C252 chipset, the X12STL-IF
motherboard provides system performance, power eciency, and feature sets to address the
needs of next-generation computer users.
The X12STL-IF dramatically increases system performance for a multitude of server
applications.
The Intel Xeon E-2300, 10th Generation Pentium processor and the C252 chipset support
the following features:
• Intel SPS 6.x
• Intel TXT
• Intel Virtual RAID on CPU (SATA RAID)
• IO Flex
• eSPI
Note: Intel TXT is only supported in the UEFI boot mode. Please install the UEFI OS
and then enable the Intel TXT feature.
1.3 Special Features
Recovery from AC Power Loss
The Basic I/O System (BIOS) provides a setting that determines how the system will respond
when AC power is lost and then restored to the system. You can choose for the system to
remain powered o (in which case you must press the power switch to turn it back on), or
for it to automatically return to the power-on state. See the Advanced BIOS Setup section
for this setting. The default setting is Last State.
1.4 System Health Monitoring
Onboard Voltage Monitors
The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage
becomes unstable, a warning is given, or an error message is sent to the screen.
