Supermicro X12STL-IF User Manual

53
Chapter 2: Installation
C
A
PRESS FIT
A
BAR CODE
REV:1.01
X12STL-IF
DESIGNED IN USA
BIOS LICENSE
JD1
MH4
MH2
JPL1
JL1
JPME2
I-SATA5
JSD1
I-SATA4
BT1
JSMB1
JPV1
MH1
FAN1
FAN2
JPWR1
MH3
JF1
JPI2C1
FAN3
JUIDB1
JMD1_SRW1
JTPM1
LED1
JBT1
JMD1
JPCIE1
JRF1
FANA
JPG1
JCPLD1
JVRM1
JPL2
JWD1
LED3
LED2
LEDM1
CPU
DIMMB1
CPU SLOT7 PCI-E 4.0 X16
DIMMA1
OH
NIC1
VGA
X
PWR
HDD LED
PWR LED
RST
FF
I-SATA0-3
LAN1/2
JF1:
NIC2
ON
USB 6/7(3.2)
USB 2/3
COM
USB 0/1
USB 4/5(3.2)
BMC_LAN
UID
JSD2
LAN LEDs
Two LAN ports (LAN1/2) are located on the I/O back panel. Each LAN port has two LEDs.
The green LED indicates activity, while the other Link LED may be yellow, amber, or o󰀨 to
indicate the speed of the connection. Refer to the tables below for more information.
1
1. LAN Port LED
LAN Activity LED (Left)
LED State
Color Status Denition
Green Flashing Active
LAN Link LED (Right)
LED State
LED Color Denition
Green 1000 Gbps
Amber/Yellow 100 Gbps
