Supero SC847A-R1400LPB User Manual

E-18
SC847 Chassis Manual
CBL-0166L
(external cable)
CBL-0168L
with Single Port Assembly
(internal cable)
Connecting Multiple Backplanes in a Dual Channel
Environment
This section describes the cables used when cascading from a single HBA. These
connections use CBL-0168L internal cables and CBL-0166L external cables.
Power Card
HBA (Host Bus Adapter)
HBA (Host Bus Adapter)
Figure E-14: Connecting Multiple Backplanes when using Dual Channels
