Chapter 1: Introduction
1-5
Jumper Description Default Setting
JBT1 CMOS Clear See Chapter 2
JI
2
C1/JI
2
C2 SMB to PCI Slot#1/Slot#2 Speed Pins 2-3 (Disabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPA1 SAS Enable Pins 1-2 (Enabled)
JPA2 Software RAID Enable Pins 1-2 (Enabled)
JPL1/ JPL2 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPWF PWR Supply Failure Detect Off (Disabled)
JWD (JWD1) Watch Dog Pins 1-2 (Reset)
Connector Description
ATX PWR (JPW1) Primary 24-Pin ATX PWR Connector
CPU PWR (JPW3) +12V 8-pin PWR
Alarm Reset (JAR) Alarm Reset Header
Chassis Intru.(JL1) Chassis Intrusion Header
COM1/COM2 (JCOM1/2) COM1/COM2 Serial Port Connectors
DIMM#1A-DIMM#2C Memory DDRII Fully Buffered DIMM Slots
FAN 1-6 Fans 1-6: System cooling fans, chassis fans, CPU fans
Floppy (J22) Floppy Disk Drive Connector
FP Control (JF1) Front Control Panel Connector
GLAN 1/2 (JLAN1/2) G-bit Ethernet Ports
IDE1 (JIDE1) IDE1 Hard Drive
Keyboard/Mouse (JKM1) Keyboard/Mouse Connectors
Parallel (J21) Parallel (Printer) Port
PWR LED/SPKR (JD1) Power LED(pins1-3)/SpeakerHeader (pins 4-7)
PWR Force-On (JPF) Power Force-On
PWR SMB (JPI
2
C) Power System Management (I
2
C) Header
PWR Supply Fail (JPWF) Power Supply Failure (See Chapter 2)
SAS0-SAS7 Serial Attached SCSI Connectors (#0-#7) (*X7DVL-3)
SATA0-SATA5 (JS1-JS6) Intel SATA 0-5 Connectors
SIMLP (J16) IPMI SIMM Low-profi le Slot
T-SGPIO#0/1 Serial ATA General Purpose Input/Output Headers
3-SGPIO#0/1 SAS General Purpose Input/Output Headers(*X7DVL-3)
Slot1 PCI 33MHz Slot
Slot5 PCI-X 133MHz Slot
Slot6 PCI-X 133MHz Slot and PCI-Express x 8 Slot
USB 0/1 (J20) Back Panel USB 0/1
USB 2/3/4/5 (JUSB1/2) Front Panel USB 2/3 (JUSB1)/FPUSB 4/5 (JUSB2)
VGA (J15) VGA Port
WOL (JWOL) Wake-on-LAN Header
WOR (JWOR) Wake-on-Ring Header
LED Indicator Description
D31 Status LED (*See Chapter 2)
LE1 Power LED (*See Note 4 on the previous page.)
LE2/LE3 (*See Chpt. 2) CPU1 VRM Overheat(LE2)/CPU2 VRM Overheat (LE3)
LE4/LE5 POST LED Indicators (*See Chapter 2)
Quick Reference (X7DVL-3/X7DVL-i)
