X7DVL-3/X7DVL-i User's Manual
Motherboard Features
CPU
• Dual Intel
®
64-bit Xeon LGA 771 Quad Core/Dual Core processors at a front
side bus speed of 1333 MHz/1067 MHz/667MHz
Memory
• Six 240-pin DIMM sockets with support up to 16 GB ECC FBD (Fully Buff-
ered) DDR2 667/533 Memory (*See Section 2-3 in Chapter 2 for DIMM Slot
Population.)
Chipset
• Intel 5000V (Blackford-VS) chipset, including: the 5000V Memory Control Hub
(MCH) and the Enterprise South Bridge 2 (ESB2)
Expansion Slots
• One PCI-Exp. x8 slot (Slot6)
• Two 64-bit PCI-X 133MHz slots (Slot5/Slot6)
• One 32-bit PCI 33 MHz slot (Slot1)
• One Low Profi le SIMLP IPMI (J16)
BIOS
• 8 Mb Phoenix
®
Flash ROM
• DMI 2.3, PCI 2.2, ACPI 1.0, Plug and Play (PnP), USB Keyboard support,
Hardware BIOS Virus Protection and SMBIOS 2.3
PC Health Monitoring
• Onboard voltage monitors for CPU cores, +1.8V, +3.3V, +5V, +12V, −12V,
+3.3V standby, +5V standby and VBAT)
• Fan status monitor with fi rmware control
• CPU/chassis temperature monitors
• Low noise fan speed control
Platform Environment Control Interface (PECI) ready
• CPU fan auto-off in sleep mode
• Pulse Width Modulation (PWM) fan control
• I
2
C temperature sensing logic
• Thermal Monitor 2 (TM2) support
• CPU slow-down on temperature overheat
• CPU thermal trip support for processor protection
• Power-up mode control for recovery from AC power loss
• Chassis intrusion detection
• System resource alert via Supero Doctor III
