X8SIL/X8SIL-F LED Indicators
Number LED Description Color/State Status
26 LE4 Onboard Standby PWR LED Green: Solid on PWR On
15 LE7 IPMI Heartbeat LED Yellow: Blinking IPMI: Normal
X8SIL/X8SIL-F Headers/Connectors
Number Connector Description
4,16 COM1/COM2 COM1/2 Serial connection headers
33,32,27,23,7 Fans 1~5 System/CPU fan headers
34 Floppy Floppy Disk Drive connector
5 JAR Alarm Reset
30 JD1 Speaker header (Pins 3/4: Internal, 1~4:External)
28 JF1 Front Panel Control header
18 JL1 Chassis Intrusion header
29 JLED Power LED Indicator header
37 JPW1 24-pin ATX main power connector (required)
36 JPW2 +12V 8-pin CPU power connector (required)
1 KB/Mouse Keyboard/mouse connectors
8,9 LAN1~LAN2, Gigabit Ethernet (RJ45) ports (LAN1/LAN2)
22 I-SATA 0~5 Serial ATA ports (X8SIL has 4 Serial ATA Ports)
2 IPMI IPMI LAN Port (X8SIL-F Only)
35 JPI2C PWR supply (I
2
C) System Management Bus
31 SPKR1 Internal speaker/buzzer
24 T-SGPIO-0/1 Serial General Purpose IO headers (for SATA)
3,21 USB0/1, USB 2/3 Backplane USB 0/1, Front panel accessible USB 2/3
20 USB 4 Type A USB Connector
19 USB 10/11 Front Panel USB header (X8SIL-F Only)
6 VGA Onboard Video Port
