1-6
X8SIL/X8SIL-F User’s Manual
Motherboard Features
CPU Single Intel® Xeon® 3400 series processor in an LGA1156
socket.
Memory Four (4) 240-pin, DDR3 SDRAM DIMM sockets with sup-
port for up to 16GB of UDIMM or up to 32GB of RDIMM
memory (ECC/DDR3 1333/1066/800 MHz memory only.)
Supports dual-channel memory bus
DIMM sizes
UDIMM 1 GB, 2 GB, and 4GB
RDIMM 1 GB, 2GB, 4GB, and 8GB
Chipset Intel® 3420 Chipset (X8SIL-F)
Intel® 3400 Chipset (X8SIL)
Expansion Slots Two (2) PCI Express 2.0 (x8) slot
One (1) PCI Express x4 (x8) slot
One (1) 32-bit PCI 33MHz slot
Integrated Graphics Matrox® G200eW
Network Connections Two Intel 82574L Gigabit (10/100/1000 Mb/s) Ethernet
Controllers for LAN 1 and LAN 2 ports.
Two (2) RJ-45 Rear IO Panel Connectors with Link and
Activity LEDs
Single Realtek RTL8201N PHY to support IPMI 2.0
(X8SIL-F Only)
I/O Devices SATA Connections (X8SIL-F)
SATA Ports Six (6)
RAID (Windows) RAID 0, 1, 5, 10
RAID (Linux) RAID 0, 1, 10
SATA Connections (X8SIL)
SATA Ports Four (4)
Integrated IPMI 2.0 (X8SIL-F)
IPMI 2.0 supported by the WPCM450 Server BMC
Floppy Disk Drive
One (1) oppy drive interface (up to 1.44 MB)
USB Devices (X8SIL)
Two (2) USB ports on the rear IO panel
Two (2) USB header connectors for front access
One (1) Type A internal connector
