1-14
X8SIL/X8SIL-F User’s Manual
1-7 Overview of the Winbond WPCM450-G (X8SIL) /
WPCM450-R (X8SIL-F) Controller
The Winbond WPCM450-G, a Baseboard Management Controller (BMC), supports
the 2D/VGA-compatible Graphics Core with the PCI interface, Virtual Media, and
Keyboard/Video/Mouse (KVM) Redirection modules. The WPCM450-R has all the
features of the WPCM450-G and includes IPMI 2.0 support.
The WPCM450 BMC interfaces with the host system via a PCI interface to com-
municate with the graphics core. It supports USB 2.0 and 1.1 for remote keyboard/
mouse/virtual media emulation. It also provides LPC interface to control Super I/O
functions. The WPCM450 is connected to the network via an external Ethernet
PHY module.
The WPCM450 communicates with onboard components via six SMBus interfaces,
fan control, Platform Environment Control Interface (PECI) buses, and General
Purpose I/O (T-SGPIO) ports.
The WPCM450 also includes the following features:
One X-Bus parallel interface for expansion I/O connections•
Three ADC inputs, Analog and Digital Video outputs•
Two serial for boundary scan and debug•
Note: For more information on IPMI conguration, please refer to the
Embedded IPMI User's Guide posted on our website @ http://www.super-
micro.com/support/manuals/.
